AAFHTFC – Aluminium High Temperature Filter Housing 10 (13) bar

£35.00 – £1,237.00

AAFHTFC filter housings have been specifically developed for very high efficient removal of solid particles, water and oil aerosols, from compressed air systems in high temperature applications.

Please call us on +353 18464303  for quotation & queries

SKU: N/A Category:

Description

AAFHTFC filter housings have been specifically developed for very high efficient removal of solid particles, water and oil aerosols, from compressed air systems in high temperature applications. To meet the required compressed air quality appropriate filter element must be installed into filter housing.

Applications

 General industrial application
 Automotive
 Electronics
 Food & Beverage
 Chemical
 Petrochemical
 Plastics
 Paint

Technical Specification

Operating temperature                1,5 – 120 °C                   35 – 248 °F
Operating pressure                        0 – 10 bar(g)                  0 – 145 psi

Materials

Housing Material Aluminium
Fittings, Screws Steel-zinc plated
Cover PA6
Sealing FKM
Corrosion Protection Electrophoretic Coating (KTL)
Outside Protection Powder paint coated (Epoxy-polyester base)
Lubricant Shell cassida grease RLS 2



Sizes

See attached PDF

Additional information

Pipe Size & Flow Rate

1/8", 6 scfm, 1/4", 11 scfm, 1/4", 15 scfm, 3/8", 18 scfm, 1/4", 22 scfm, 3/8", 35scfm, 1/2", 46 scfm, 3/4", 70 scfm, 1", 116 scfm, 1", 197 scfm, 1 1/2", 300 scfm, 1 1/2", 459 scfm, 2", 588 scfm, 2", 882 scfm, 2 1/2", 990 scfm, 3", 1270 scfm, 3", 1620 scfm
Filter Element

BHT (15 micron), N25HT (25 micron), N5HT (5 micron), XRHT (1 micron), XMHT (0.1 micron), XSHT (0.01 micron), CKLHT (Separator), Housing Only
